Blades

6.9 m³ (9.0 yd³) Variable Radius Semi U-Blade

Capacity
9.0 yd3
Width
168.0 in
Height
50.0 in
Details

7.8 m³ (10.3 yd³) Variable Radius Semi U-Blade

Capacity
10.3 yd3
Width
177.0 in
Height
55.0 in
Details

9.66 m³ (13 yd³) Coal U-Blades

Capacity
12.6 yd3
Width
168.0 in
Wing Angle
30.0 Degrees
Details

13.38 m³ (17.5 yd³) Coal Blade

Capacity
17.5 yd3
Width
168.0 in
Wing Angle
30.0 Degrees
Details

14.8 m³ (19.4 yd³) Coal U-Blade

Capacity
19.4 yd3
Width
193.0 in
Wing Angle
30.0 Degrees
Details

15.3 m³ (20.0 yd³) Woodchip U-Blade

Capacity
20.0 yd3
Width
168.0 in
Wing Angle
30.0 Degrees
Details

16.4 m³ (21.5 yd³) Reclamation U-Blade

Capacity
21.5 yd3
Width
192.0 in
Wing Angle
28.0 Degrees
Details

18.35 m³ (24.0 yd³) Landfill U-Blade

Capacity
23.7 yd3
Width
168.0 in
Wing Angle
30.0 Degrees
Details

21.41 m³ (28.0 yd³) Coal U-Blade

Capacity
28.0 yd3
Width
218.0 in
Wing Angle
30.0 Degrees
Details

23.8 m³ (30.8 yd³ ) Woodchip U-Blade

Capacity
30.8 yd3
Width
193.0 in
Wing Angle
30.0 Degrees
Details

23.32 m³ (30.5 yd³) Landfill U-Blade

Capacity
30.5 yd3
Width
194.0 in
Wing Angle
30.0 Degrees
Details

23.70 m³ (31.0 yd³) Landfill U-Blade

Capacity
31.0 yd3
Width
217.0 in
Wing Angle
30.0 Degrees
Details

28.3 m³ (37.0 yd³) Woodchip U-Blade

Capacity
37.0 yd3
Width
216.0 in
Wing Angle
30.0 Degrees
Details

30.6 m³ (40.0 yd³) Reclamation U-Blade

Capacity
40.0 yd3
Width
224.0 in
Wing Angle
28.0 Degrees
Details

36.70 m³ (48.0 yd³) Coal U-Blade

Capacity
48.0 yd3
Width
226.0 in
Wing Angle
30.0 Degrees
Details

38.23 m³ (50.0 yd³) Landfill U-Blade

Capacity
50.0 yd3
Width
214.0 in
Wing Angle
30.0 Degrees
Details

45.9 m³ (60.0 yd³) Woodchip U-Blade

Capacity
60.0 yd3
Width
215.0 in
Wing Angle
30.0 Degrees
Details

52.0 m³ (68.0 yd³) Coal U-Blade

Capacity
68.0 yd3
Width
265.0 in
Wing Angle
30.0 Degrees
Details

53.5 m³ (70.0 yd³) Reclamation U-Blade

Capacity
70.0 yd3
Width
287.0 in
Wing Angle
30.0 Degrees
Details

63.46 m³ (83.0 yd³) Coal U-Blade

Capacity
83.0 yd3
Width
270.0 in
Wing Angle
30.0 Degrees
Details

65.75 m³ (86.0 yd³) Coal U-Blade

Capacity
86.0 yd3
Width
290.0 in
Wing Angle
30.0 Degrees
Details

72.6 m³ (95.0 yd³) Woodchip U-Blade

Capacity
95.0 yd3
Width
265.0 in
Wing Angle
30.0 Degrees
Details

74.93 m³ (98.0 yd³) Coal U-Blade

Capacity
98.0 yd3
Width
322.0 in
Wing Angle
30.0 Degrees
Details

1829 mm (72 in) Angle Blade

Overall width
72.0 in
Working width (fully angled)
66.0 in
Maximum blade angle (right/left of center)
30.0 Degrees
Details

2007 mm (79 in) Dozer Blade

Overall Width
79 in
Width - Fully Angled
68.9 in
Maximum Blade Angle - Right/Left of Center
30 degrees
Details

2134 mm (84 in) Angle Blade

Overall width
84 in
Working width (fully angled)
78 in
Maximum blade angle (right/left of center)
30 Degrees
Details

2337 mm (92 in) Dozer Blade

Overall Width
92 in
Width - Fully Angled
80.7 in
Maximum Blade Angle - Right/Left of Center
30 degrees
Details

2337 mm (92 in) Dozer Blade with Smart Technology

Overall Width
92 in
Width - Fully Angled
80.7 in
Maximum Blade Angle - Right/Left of Center
30 degrees
Details

3048mm (120 in) Cushion Dozer Blade

Width
120.0 in
Height
62.0 in
Weight
9420.0 lb
Details

3505mm (138 in) Cushion Dozer Blade

Width
138.0 in
Height
70.0 in
Weight
13480.0 lb
Details

GB120 Grader Blade

Overall Width
78.4 in
Moldboard - Blade Width
78 in
Width - Fully Angled
68.8 in
Details

GB124 Grader Blade

Overall Width
96.4 in
Moldboard - Blade Width
96 in
Width - Fully Angled
84.4 in
Details
