Overall Width
126in
Sweeping Width
118.1in
Brush Diameter
36in
Required Hydraulics
Standard Flow
Height
59.8in
Length
64.2in
Weight
1124.4lb
Optimal Hydraulic Flow
42-300 L/min (11-80 gpm)
Optimal Hydraulic Pressure
150-260 bar (2176-3771 psi)
Motor Displacement
18.9in³/rev
Brush Speed at Maximum Flow
303 RPM
Sweeping Width – Angled (± 30 Degrees)
102.4in
Overall Width – Angled (± 30 Degrees)
110.2in
Drive Method
Direct Drive
Interface Type
Requires Hook Group
Voltage Type
24V
