914 mm (36 in) 1 Ton Mini Excavator Pin Lock Compaction Wheel

Cat® Compaction Wheels for Backhoe Loaders and Mini Excavators provide a low cost option for trench compaction. The wheels feature tapered roller bearings and tampered foot design with static pad rollers, to allow for smooth operation and achieving a high level of compaction. Six to ten passes are usually adequate to achieve compaction in normal soil conditions, dependent on the required compaction levels.

Compaction Width
34.8in
Number of Wheels
5
Machine Class
1 Ton Mini Excavators
Number of Pads
45
Weight
1970.9lb
Overall Length
42.2in
Overall Height
50.6in
Overall Width
34.8in
Interface Type
Pin Lock
