Machine Class
7-9 Ton Mini Excavator
Weight
711.9lb
Interface Options: Top-Bottom
Pin On / S-45
Overall Height
37.7in
Length
26in
Overall Width
26.7in
Rotation Speed
7 Seconds per 1 full rotation
Tilt Angle Range +/-
40° Left/Right
Maximum Bucket Capacity
17.7ft³
Maximum Bucket Width
59.1in
Optimal Hydraulic Flow
45-75 L/min (12-20 gpm)
Maximum Operating Pressure
3625.9psi
Required Hydraulics
1st Auxiliary
Tilting Torque
19545.4lb/ft
Turning Torque
2876.5lb/ft
