Maximum Cutting Depth
31.5in
Wheel Width
9.8in
Weight
3196.7lb
Overall Width
65.2in
Overall Height
73.2in
Length
102.4in
Required Hydraulics
High Flow XHP / XE
Optimal Hydraulic Flow
136-150 L/min (36-40 gpm)
Optimal Hydraulic Pressure
250-280 bar (3630-4000 psi)
Motor Displacement
102.9in³/rev
Wheel Torque at Maximum Pressure
5538.4lb/ft
Wheel Speed at Maximum Flow
89 RPM
Bit Speed at Maximum Flow
1456.7ft/min
Conical Bits – Per Wheel
72
Standard Bit Type
Concrete
Optional Bit Type
All Purpose
Side Shift Travel
21.7in
Trench Cleaning Device
No
Drive Method
Direct Drive
Interface Type
Skid Steer Coupler
