Machine Class
14-19
Interface Options: Top-Bottom
Pin-on / HCS60
Rotation Speed
7 seconds, per 1 full rotation
Tilt Angle Range +/-
40° Left/Right
Maximum Bucket Capacity
1.31yd³
Maximum Bucket Width
68in
Optimal Hydraulic Flow
111 L/min (29 gpm)
Maximum Operating Pressure
3626psi
Tilting Torque
33264lb/ft
Turning Torque
7044lb/ft
